- Exclusive 6 core 32bit DSP processor chip,DRC music processor
- Double TDA7851L amplifier built in
- Built in bluetooth 5.0
- 32-bit 300MHz floating point procesing
-4CH hi-level input/AUX-R/L low level input/Optical input/USB input/Bluetooth input
-8CH hi-level output/8RCA low level output
-8X150W MAX.power outputs (high level),RMS.8X50W
- 31bands of independent equalization per channel
- Parametric and Graphic equalizer
- Frequency range 20Hz~20KHz,1Hz steps
- Q:0.40~128 0.01 steps
- Gain:-20.0dB~+20dB,0.1dB steps
- High pass,low pass
- Phase control
- Specialized type fitering:Butterworth,Linkwitz-Rile,Bessel
- Filter crossover pionts:20Hz-20KHz,1Hz steps
- Slopes:6dB,12dB,18dB,24dB,30dB,36dB,42dB,48dB
- up to 20ms of time delay per channel delay unit (ms,cm,inch)
- Save and share tuning presets (8 presets mode available)
- Sources:Bluetooth audio,High-level input (head unit signal),U disc,Analog AUX inputs
(aftermarket head unit signal)
- Steering wheel control for volume,preset store/recall,source selection (exta selection)
- Matrix mixing allows for summing and input/output signal management.
- Android app free download
- Windows system software free download
- Limiter:0.1dBu~6dBu 0.1dBu steps
-Release Time: Atk*2,Atk*4,Atk*6,Atk*8,Atk*16,Atk*32
- AT.time:0.3ms~100ms 0.1ms steps
- T.H.D<0.01%
- Isolation>90dB
- S/N>108dB
